All 3D Systems' DMP printers create chemically pure, fully dense metal and ceramic parts, and they deliver accuracy compatible with EN ISO 2768 (fine) machining tolerances and a repeatability of about 20 microns in all three axes. Materials include stainless steel, tool steel, super alloys, non-ferrous alloys, precious metals and alumina. The outstanding output quality, with high accuracy, finish, reliability and repeatability, and a choice of more than 15 materials, makes these industry-leading machines highly attractive to manufacturers.
ProX DMP 3D printers provide seamless and intuitive metal 3D printing in a variety of industries: custom dental prostheses, orthopedic implants, tire molds, watch manufacturing, aerospace parts and more. In addition, these systems are wisely used for direct creation of conformal tooling, tooling insert and blow mold production.
ProX® DMP 100
Production 3D Printer
Manufacture small, complex metal parts in hours
The ProX® range of Direct Metal Printing (DMP) 3D printers builds on 3D Systems' stellar laser sintering capabilities by incorporating 10 years of research and development in metal 3D printing.
The smallest of the ProX DMP line, the ProX DMP 100 is designed as the starting point for people wishing to manufacture small, complex metal parts at high quality and speed using DMP. The ProX DMP 100 features a build volume of 100mm x 100mm x 80mm along with manual material loading and an optional external recycling station. The system supports materials including Stainless 17-4PH and CoCr. The ProX DMP 100 also includes 3D Systems' software tools, which are specifically designed to ensure successful direct metal manufacturing processes.
Benefits
ProX® DMP 200
Production 3D Printer
Medium-sized build volume in a powerful metal 3D printing package
The latest addition to the ProX® range, the ProX DMP 200 integrates a powerful laser adapted to an intermediary production volume for the streamlined manufacturing of precise, medium-sized metal parts. The ProX DMP 200 is a high-performance, high-quality alternative to traditional manufacturing processes, offering reduced waste, greater speeds for production, short set up times, very dense metal parts, and the ability to produce very complex assemblies as a single part. In addition, the ProX DMP 200 gets you to your part faster with seamless, intuitive 3D printing software.
The ProX DMP 200 system offers a build volume of 140mm x 140mm x 100mm height. It features semi-automated material loading and an optional external recycling system, and supports materials, including Maraging 1.2709, Stainless 17-4PH, CoCr, and AlSi12.
Benefits
Build metal parts with fast build speeds
Robust manufacturing floor platform
Exceptional surface finish and resolution
Create fully dense metal parts
Minimal waste of materials
Able to produce parts not normally manufacturable using traditional methods
ProX® DMP 300
Production 3D Printer
Metal 3D printing for industrial applications
3D Systems brings its legendary reliability and repeatability to production-level Direct Metal Printing (DMP) with the ProX® DMP 300 3D printer.
The ProX DMP 300 3D printer makes additive manufacturing an industrial option for the production of metal parts. The ProX DMP 300 is the largest in our DMP range, offering a build volume of 9.8 x 9.8 x 11.8 in (250 x 250 x 300 mm). It features an automated material loading and recycling system, and supports materials including Maraging 1.2709, Stainless 17-4PH, CoCr, and AlSi12.
The ProX DMP 300 is a high-performance, high-quality alternative to traditional manufacturing processes, offering reduced waste, greater speeds for production, short set up times, very dense parts, and the ability to produce very complex assemblies as a single parts.
Benefits
Robust manufacturing floor platform
Patented powder layering system guarantees outstanding quality
Exceptional surface finish and resolution
Excellent accuracy and repeatability
Fully dense parts with superior mechanical properties
Fast build speeds
